Amplicon Impact-R 4000S series

4U industrial motherboard based computer. Core-i processing power. Shallow depth

Short depth (302mm)
8th, 9th and 10th gen Intel processors
Supports Intel Core i5/i7 processors
Two front USB ports
15 year life cycle
3 year warranty package

The Amplicon Impact-R 4000S industrial PC incorporates industrial motherboards to achieve hardware life cycles of up to five years.

With only 302mm depth, the Impact-R 4000S systems have been specifically designed for limited space environments. Despite the compact size, the systems offer outstanding high performance using the powerful Intel® Core™ processor technology.

These industrial PC's provide a wide performance range to meet different application requirements. As with all our industrial computing systems, they can be tailored to meet your requirements.

Amplicon's systems are able to offer a 15 year life cycle based on the Intel IoTG roadmap. 8th, 9th and 10th generation processor options are available.

Chassis Size: 4 U
CPU: Core i5; Core i7
Memory: 2 GB; 8 GB
OS Support: Linux; Windows 10; Windows 10 IoT; Windows 7; Windows Emb Std 7
Expansion: PCI; PCIe; mPCIe; M.2
Memory Type: DDR3; DDR4
Storage: 256GB M.2; 500GB HDD
Chipset: Intel® H310; Q470E; Intel® Q87; Intel® Q370
CPU Generation: 4th (Haswell); 8th (Coffee Lake); 9th (Coffee Lake refresh); 10th (Cometlake)
CPU Cores (Physical): 6; 8
Max Memory: 32 GB; 64 GB; 128 GB
Max Operating Temperature: 60 °C
Mounting: Rack
Chassis depth: Shallow depth
Brand: Impact-R

Impact-R_4080S_H310: Datasheet 319.40 KB
impact-r-roadmap: Roadmaps 181.18 KB
